Introduction

In The Ultimate Guide to KServe, we walked through KServe’s architecture, deployment modes, and how to get an LLMInferenceService running on GKE. That guide solved the “what” and “how” of model serving. But once your first inference service is live, a new set of questions emerges: How do you version your KServe configurations? How do you promote model deployments from staging to production safely? How do you roll back a broken inference service at 2 AM without SSH-ing into a cluster and running kubectl by hand?

The answer is GitOps—and more specifically, ArgoCD.

This blog is the natural sequel to our KServe guide. Where the previous post ended with a manually deployed LLMInferenceService, this one picks up by wrapping that entire deployment lifecycle in a declarative, version-controlled, auditable GitOps pipeline. We’ll use ArgoCD to manage both predictive and generative AI models—ResNet-50, Sentence-BERT, and Mistral-7B—through a single Git repository, complete with canary rollouts, KEDA autoscaling, InferenceGraphs, and Prometheus monitoring.

Everything in this guide is backed by a complete, open-source reference implementation:

Explore the KServe GitOps Reference Repository →

What You’ll Learn in This Blog

In this advanced guide, you’ll discover:

• The Gap: Why kubectl apply is not a production deployment strategy, and the specific operational risks it introduces for AI inference workloads
• GitOps Fundamentals for AI Infrastructure: How GitOps principles map to KServe resources, and why ArgoCD is the ideal fit for managing inference services declaratively
• Repository Design: How to structure a GitOps repository that separates predictive models, generative models, InferenceGraphs, and monitoring into distinct ArgoCD Applications with scoped permissions
• Hands-On Lab: End-to-end walkthrough—from bootstrapping the KServe control plane through ArgoCD, to deploying ResNet-50, Sentence-BERT, and Mistral-7B via Git commits, to performing canary rollouts by changing a single YAML field
• Production Hardening: Sync waves for dependency ordering, self-healing drift detection, ApplicationSets for multi-cluster AI serving, and LocalModelCache for eliminating LLM cold starts

By the end, you’ll have a production-grade blueprint where every infrastructure change is a pull request, every deployment is auditable, and every rollback is a git revert.

The Gap: Why KServe Alone Isn’t Enough for Production

In our previous guide, we deployed KServe components and inference services using a sequence of helm install and kubectl apply commands. This approach works perfectly for learning and experimentation, but it introduces serious operational risks when you move to production.

The KServe stack is particularly vulnerable to these problems because of its layered dependency chain. A working KServe deployment requires Istio, Knative Serving, KServe CRDs, KServe controller, KEDA, ServingRuntimes, and finally the inference services themselves. Each component has version dependencies on the others, and they must be installed in a specific order. Managing this imperatively across multiple environments is a recipe for production incidents.

This is precisely the problem that GitOps—and ArgoCD in particular—was designed to solve.

I. GitOps Fundamentals for AI Infrastructure

1. What is GitOps?

GitOps rests on four core principles that map directly to the challenges of managing AI infrastructure:

1. Declarative Configuration: Your entire KServe stack—from KEDA autoscaling policies to LLMInferenceService manifests—is described declaratively in YAML and stored in Git. There are no imperative scripts or manual kubectl commands required.

2. Versioned and Immutable: Every change to your AI serving infrastructure is a Git commit. Want to know who changed the GPU limits on the Mistral deployment? Check the Git log. Need to understand why autoscaling behavior changed? Read the diff.

3. Pulled Automatically: An agent running inside your cluster (ArgoCD) continuously pulls the desired state from Git and applies it. You don’t push configurations to the cluster—the cluster pulls them.

4. Continuously Reconciled: The agent doesn’t just apply changes once. It continuously compares the desired state (Git) with the actual state (cluster) and corrects any drift. If someone manually edits a KServe resource, ArgoCD will detect the change and revert it.

2. Why ArgoCD for KServe?

ArgoCD is a CNCF-graduated project and the most widely adopted GitOps engine for Kubernetes. Several characteristics make it particularly well-suited for managing KServe deployments:

As explored in the excellent reference How to Manage Kubeflow Pipelines with ArgoCD, ArgoCD excels at managing complex ML infrastructure stacks with many interdependent components. The patterns established there for Kubeflow Pipelines—structured GitOps repositories, sync wave ordering, environment overlays—translate directly to KServe deployments. This guide builds on those same foundational patterns while adapting them for KServe’s specific architecture.

3. The GitOps + KServe Architecture

The high-level architecture is straightforward: Git is the source of truth, ArgoCD is the reconciliation engine, and KServe is the execution layer.

The workflow is as follows:

1. An engineer commits a change to the Git repository (e.g., updating a model image tag, adding a new InferenceService, or adjusting autoscaling thresholds)
2. ArgoCD detects the diff between the desired state (Git) and the actual state (cluster)
3. ArgoCD syncs the changes—creating, updating, or pruning Kubernetes resources
4. KServe’s controllers reconcile the InferenceService/LLMInferenceService resources, orchestrating pods, services, and routing
5. If the cluster state drifts from Git (manual kubectl edit, operator mutation, etc.), ArgoCD’s self-heal loop corrects it automatically

This separation of concerns is powerful: Git owns the “what,” ArgoCD owns the “when,” and KServe owns the “how.”

II. Designing the GitOps Repository Structure

1. Repository Layout

The reference implementation at github.com/AymenSegni/kserve-argo-ml-reference follows a deliberate structure that separates concerns cleanly:

kserve-argo-ml-reference/
├── argocd/
│   ├── project.yaml                    # AppProject: permission boundaries
│   └── applications/
│       ├── predictive.yaml             # ArgoCD App → kserve/predictive/
│       ├── generative.yaml             # ArgoCD App → kserve/generative/
│       ├── graphs.yaml                 # ArgoCD App → kserve/graphs/
│       └── monitoring.yaml             # ArgoCD App → monitoring/
├── kserve/
│   ├── predictive/                     # Predictive ML models
│   │   ├── resnet50-isvc.yaml
│   │   └── sentence-bert-isvc.yaml
│   ├── generative/                     # Generative LLM models
│   │   ├── mistral-isvc.yaml           # Knative mode (batch)
│   │   ├── mistral-realtime-isvc.yaml  # Standard mode (KEDA)
│   │   ├── mistral-llmisvc.yaml        # LLMInferenceService (v0.17+)
│   │   ├── local-model-cache.yaml      # Pre-cache LLM weights
│   │   ├── local-model-nodegroup.yaml
│   │   └── serviceaccount.yaml
│   ├── canary/
│   │   └── resnet50-canary-isvc.yaml   # Canary rollout example
│   ├── autoscaling/
│   │   └── keda-mistral.yaml           # Standalone KEDA ScaledObject
│   └── graphs/
│       └── ml-pipeline-graph.yaml      # InferenceGraph (Ensemble + Sequence)
├── monitoring/
│   ├── servicemonitors.yaml            # Prometheus ServiceMonitors
│   └── alerting-rules.yaml             # PrometheusRule alert definitions
├── models/                             # Custom model server source code
│   ├── resnet50-server/
│   │   ├── model.py
│   │   ├── Dockerfile
│   │   └── requirements.txt
│   └── sentence-bert-server/
│       ├── model.py
│       ├── Dockerfile
│       └── requirements.txt
├── scripts/
│   ├── setup/                          # One-time setup scripts
│   │   ├── setup_controlplane.sh
│   │   ├── setup_argocd.sh
│   │   ├── setup_namespaces.sh
│   │   └── setup_secrets.sh
│   ├── validate/                       # Validation scripts
│   └── smoke/                          # End-to-end smoke tests
└── docs/
    ├── kserve-features-reference.md
    └── model-onboarding-guide.md

The key design principle: each ArgoCD Application maps to exactly one directory, and each directory contains one category of KServe resources. This means you can deploy and manage predictive models independently from generative models, and both independently from monitoring. A failed sync in the monitoring Application doesn’t block your model deployments.

2. The ArgoCD AppProject: Scoping Permissions

Before creating any Applications, we define an AppProject that scopes what resources ArgoCD is allowed to manage. This is a security boundary—it prevents a misconfigured Application from accidentally modifying resources outside the ML platform namespaces.

# Source: https://github.com/AymenSegni/kserve-argo-ml-reference/blob/main/argocd/project.yaml
apiVersion: argoproj.io/v1alpha1
kind: AppProject
metadata:
  name: kserve-gitops-blueprint
  namespace: argocd
spec:
  description: "A production-grade GitOps blueprint for deploying generative
    and predictive AI on Kubernetes using KServe, vLLM, and ArgoCD."
  sourceRepos:
    - "https://github.com/AymenSegni/kserve-gitops-blueprint.git"
  destinations:
    - namespace: "ml-predictive"
      server: "https://kubernetes.default.svc"
    - namespace: "ml-generative"
      server: "https://kubernetes.default.svc"
    - namespace: "ml-graphs"
      server: "https://kubernetes.default.svc"
    - namespace: "ml-monitoring"
      server: "https://kubernetes.default.svc"
  clusterResourceWhitelist:
    - group: "serving.kserve.io"
      kind: "*"
    - group: "keda.sh"
      kind: "*"
  namespaceResourceWhitelist:
    - group: "serving.kserve.io"
      kind: "*"
    - group: "keda.sh"
      kind: "*"
    - group: "monitoring.coreos.com"
      kind: "*"
  orphanedResources:
    warn: true

Notice the explicit destinations list—ArgoCD can only deploy into the four ML namespaces (ml-predictive, ml-generative, ml-graphs, ml-monitoring). The clusterResourceWhitelist and namespaceResourceWhitelist further restrict which CRD types are allowed, ensuring that only KServe, KEDA, and Prometheus resources can be managed through this project.

3. ArgoCD Applications: One Per Concern

Each ArgoCD Application points to a specific directory in the Git repo and deploys its contents into a specific namespace. Here’s the generative models Application:

# Source: https://github.com/AymenSegni/kserve-argo-ml-reference/blob/main/argocd/applications/generative.yaml
apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: ml-generative
  namespace: argocd
  labels:
    app.kubernetes.io/part-of: kserve-gitops-blueprint
    app.kubernetes.io/component: inference-generative
spec:
  project: kserve-gitops-blueprint
  source:
    repoURL: "https://github.com/AymenSegni/kserve-gitops-blueprint.git"
    targetRevision: main
    path: kserve/generative
  destination:
    server: "https://kubernetes.default.svc"
    namespace: ml-generative
  syncPolicy:
    automated:
      prune: true
      selfHeal: true
    syncOptions:
      - CreateNamespace=false
      - ApplyOutOfSyncOnly=true
    retry:
      limit: 3
      backoff:
        duration: 5s
        factor: 2
        maxDuration: 3m

Several configuration choices here are deliberate for AI workloads:

• automated.prune: true: If you delete an InferenceService YAML from the repo, ArgoCD removes it from the cluster. No orphaned GPU-consuming pods.
• automated.selfHeal: true: If someone runs kubectl edit isvc mistral-batch -n ml-generative, ArgoCD reverts the change within seconds.
• ApplyOutOfSyncOnly: true: Only re-apply resources that have actually changed, avoiding unnecessary reconciliation of healthy inference services.
• retry with exponential backoff: GPU node provisioning can take minutes. The retry policy gives the cluster time to scale before marking the sync as failed.

The same pattern applies for predictive models, InferenceGraphs, and monitoring—each with its own Application pointing to its own directory.

4. Managing Secrets in a GitOps World

Secrets are the one thing you should never store in Git. The reference implementation handles this with a dedicated secrets setup script that distributes credentials before ArgoCD takes over:

# scripts/setup/setup_secrets.sh (excerpt)
# Source: https://github.com/AymenSegni/kserve-argo-ml-reference/blob/main/scripts/setup/setup_secrets.sh

# Usage:
#   export HF_TOKEN="hf_xxxxx"
#   bash scripts/setup/setup_secrets.sh

HF_SECRET_NAME="hf-token-secret"

GENERATIVE_NAMESPACES=(
  ml-generative
)

if [[ -n "${HF_TOKEN:-}" ]]; then
  for ns in "${GENERATIVE_NAMESPACES[@]}"; do
    if kubectl get secret "$HF_SECRET_NAME" -n "$ns" &>/dev/null; then
      kubectl delete secret "$HF_SECRET_NAME" -n "$ns"
    fi
    kubectl create secret generic "$HF_SECRET_NAME" -n "$ns" \
      --from-literal=HF_TOKEN="$HF_TOKEN"
    kubectl annotate secret "$HF_SECRET_NAME" -n "$ns" \
      serving.kserve.io/secretKey=HF_TOKEN --overwrite
  done
fi

The KServe manifests then reference these secrets via valueFrom.secretKeyRef—never embedding the actual token value. This clean separation means ArgoCD manages the declarative resources (InferenceServices, ServiceMonitors) while secrets are provisioned out-of-band.

III. Lab: Deploy KServe with ArgoCD

In this hands-on lab, you’ll deploy a complete ML serving platform using the kserve-argo-ml-reference repository. The platform includes three models (ResNet-50, Sentence-BERT, Mistral-7B), an InferenceGraph pipeline, KEDA autoscaling, canary rollouts, and Prometheus monitoring—all managed declaratively through ArgoCD.

1. Prerequisites

Ensure you have the following tools installed:

- kubectl
- helm
- istioctl
- argocd CLI (optional, for CLI-based management)
- A Kubernetes cluster with GPU nodes (for generative models)

Clone the reference repository:

git clone https://github.com/AymenSegni/kserve-argo-ml-reference.git
cd kserve-argo-ml-reference

2. Install the Control Plane

The control plane setup script installs Istio, Knative Serving, KServe, and KEDA idempotently:

# Source: https://github.com/AymenSegni/kserve-argo-ml-reference/blob/main/scripts/setup/setup_controlplane.sh
bash scripts/setup/setup_controlplane.sh

Under the hood, this script performs four steps in strict order:

# Step 1: Istio (minimal profile for KServe networking)
istioctl install --set profile=minimal -y

# Step 2: Knative Serving (serverless capabilities for scale-to-zero)
kubectl apply -f "https://github.com/knative/serving/releases/download/knative-v1.15.2/serving-crds.yaml"
kubectl apply -f "https://github.com/knative/serving/releases/download/knative-v1.15.2/serving-core.yaml"
kubectl apply -f "https://github.com/knative/net-istio/releases/download/knative-v1.15.2/net-istio.yaml"

# Step 3: KServe CRDs and controller
kubectl apply --server-side -f "https://github.com/kserve/kserve/releases/download/v0.17.0/kserve.yaml"
kubectl apply -f "https://github.com/kserve/kserve/releases/download/v0.17.0/kserve-cluster-resources.yaml"

# Step 4: KEDA for advanced autoscaling
helm install keda kedacore/keda --namespace keda --create-namespace --version 2.17.0 --wait

Each step is idempotent—if a component already exists, the script skips it. This makes it safe to re-run after partial failures.

Next, create the namespaces and distribute secrets:

bash scripts/setup/setup_namespaces.sh

export HF_TOKEN="hf_your_token_here"
bash scripts/setup/setup_secrets.sh

3. Install ArgoCD and Bootstrap the Platform

This is where things get interesting. A single script installs ArgoCD, applies the AppProject, and deploys all four ArgoCD Applications:

# Source: https://github.com/AymenSegni/kserve-argo-ml-reference/blob/main/scripts/setup/setup_argocd.sh
bash scripts/setup/setup_argocd.sh

Here’s what happens:

# Install ArgoCD via Helm
helm install argocd argo/argo-cd \
  --namespace argocd \
  --create-namespace \
  --version "7.7.16" \
  --set server.service.type=ClusterIP \
  --wait

# Wait for ArgoCD to be ready
kubectl wait --for=condition=available deployment/argocd-server \
  -n argocd --timeout=120s

# Apply AppProject (permission boundaries)
kubectl apply -f argocd/project.yaml

# Apply all Applications (one per directory)
kubectl apply -f argocd/applications/

After this, ArgoCD will auto-sync all manifests from the repository. Access the ArgoCD UI:

kubectl port-forward svc/argocd-server -n argocd 8080:443
# Open https://localhost:8080

# Get the admin password
kubectl -n argocd get secret argocd-initial-admin-secret \
  -o jsonpath="{.data.password}" | base64 -d

You should see four Applications in the ArgoCD dashboard: ml-predictive, ml-generative, ml-graphs, and ml-monitoring—all syncing automatically.

4. Deploy Predictive Models via GitOps

The predictive models directory contains two InferenceServices that ArgoCD auto-syncs. Here’s the ResNet-50 deployment:

# Source: https://github.com/AymenSegni/kserve-argo-ml-reference/blob/main/kserve/predictive/resnet50-isvc.yaml
apiVersion: serving.kserve.io/v1beta1
kind: InferenceService
metadata:
  name: resnet50
  namespace: ml-predictive
  annotations:
    autoscaling.knative.dev/min-scale: "0"
    autoscaling.knative.dev/max-scale: "3"
    autoscaling.knative.dev/target: "10"
    serving.kserve.io/enable-prometheus-scraping: "true"
spec:
  predictor:
    containers:
      - name: kserve-container
        image: ghcr.io/aymensegni/resnet50-server:v1
        ports:
          - containerPort: 8080
            protocol: TCP
        env:
          - name: MODEL_NAME
            value: resnet50
        resources:
          requests:
            cpu: "1"
            memory: 2Gi
          limits:
            cpu: "2"
            memory: 4Gi
        readinessProbe:
          httpGet:
            path: /v2/health/ready
            port: 8080
          initialDelaySeconds: 15
          periodSeconds: 10
        livenessProbe:
          httpGet:
            path: /v2/health/live
            port: 8080
          initialDelaySeconds: 15
          periodSeconds: 10

This uses a custom model server implementing the KServe V2 Open Inference Protocol. The server code lives in models/resnet50-server/model.py and extends kserve.Model with preprocess(), predict(), and postprocess() methods:

# models/resnet50-server/model.py (excerpt)
# Source: https://github.com/AymenSegni/kserve-argo-ml-reference/blob/main/models/resnet50-server/model.py
class ResNet50Server(kserve.Model):
    def load(self):
        weights = models.ResNet50_Weights.DEFAULT
        self.model = models.resnet50(weights=weights)
        self.model.to(self.device)
        self.model.eval()
        self.preprocess_transform = weights.transforms()
        self.categories = weights.meta["categories"]
        self.ready = True

    def preprocess(self, payload: InferRequest, headers=None):
        inputs = payload.inputs
        images = []
        for inp in inputs:
            data = inp.data[0]
            if isinstance(data, str):
                image_bytes = base64.b64decode(data)
            else:
                image_bytes = data
            img = Image.open(io.BytesIO(image_bytes)).convert("RGB")
            tensor = self.preprocess_transform(img).to(self.device)
            images.append(tensor)
        return images

    def predict(self, inputs, headers=None):
        batch = torch.stack(inputs)
        with torch.no_grad():
            outputs = self.model(batch)
            probabilities = torch.nn.functional.softmax(outputs, dim=1)
        return probabilities

The key insight: you don’t deploy this model by running a command. You commit the YAML file to Git, push, and ArgoCD handles the rest. To update the model to a new version, you change the image tag in the YAML and push again.

5. Deploy Generative Models via GitOps

The reference implementation includes three different approaches to deploying Mistral-7B, demonstrating KServe’s flexibility:

Option A: Knative Mode (Batch/Async)—scale-to-zero when idle, perfect for cost-efficient batch inference:

# Source: https://github.com/AymenSegni/kserve-argo-ml-reference/blob/main/kserve/generative/mistral-isvc.yaml
apiVersion: serving.kserve.io/v1beta1
kind: InferenceService
metadata:
  name: mistral-batch
  namespace: ml-generative
  annotations:
    autoscaling.knative.dev/min-scale: "0"
    autoscaling.knative.dev/max-scale: "2"
    serving.kserve.io/enable-prometheus-scraping: "true"
spec:
  predictor:
    model:
      modelFormat:
        name: huggingface
      env:
        - name: HF_TOKEN
          valueFrom:
            secretKeyRef:
              name: hf-token-secret
              key: HF_TOKEN
      args:
        - --model_id=mistralai/Mistral-7B-Instruct-v0.3
        - --model_name=mistral-7b
        - --dtype=bfloat16
        - --max_model_len=8192
        - --tensor_parallel_size=1
        - --backend=vllm
        - --gpu_memory_utilization=0.90
      resources:
        requests:
          cpu: "4"
          memory: 16Gi
          nvidia.com/gpu: "1"
        limits:
          cpu: "8"
          memory: 32Gi
          nvidia.com/gpu: "1"
    runtimeClassName: nvidia
    serviceAccountName: ml-generative-sa

Option B: Standard Mode with KEDA (Real-time)—always warm with at least 1 replica, autoscaling on vLLM concurrency metrics:

# Source: https://github.com/AymenSegni/kserve-argo-ml-reference/blob/main/kserve/generative/mistral-realtime-isvc.yaml
apiVersion: serving.kserve.io/v1beta1
kind: InferenceService
metadata:
  name: mistral-realtime
  namespace: ml-generative
  annotations:
    serving.kserve.io/deploymentMode: "Standard"
    serving.kserve.io/autoscalerClass: "keda"
    serving.kserve.io/enable-prometheus-scraping: "true"
spec:
  predictor:
    model:
      modelFormat:
        name: huggingface
      args:
        - --model_id=mistralai/Mistral-7B-Instruct-v0.3
        - --backend=vllm
        - --gpu_memory_utilization=0.90
      # ...same resource config as above...
    minReplicas: 1
    maxReplicas: 3
    autoScaling:
      metrics:
        - type: External
          external:
            metric:
              backend: "prometheus"
              serverAddress: "http://kube-prometheus-stack-prometheus.monitoring.svc:9090"
              query: >-
                sum(vllm:num_requests_running{namespace="ml-generative",
                pod=~"mistral-realtime-predictor.*"})
            target:
              type: Value
              value: "3"

Option C: LLMInferenceService (v0.17+)—the new simplified CRD specifically designed for LLM workloads:

# Source: https://github.com/AymenSegni/kserve-argo-ml-reference/blob/main/kserve/generative/mistral-llmisvc.yaml
apiVersion: serving.kserve.io/v1alpha1
kind: LLMInferenceService
metadata:
  name: mistral-llm
  namespace: ml-generative
  annotations:
    serving.kserve.io/enable-prometheus-scraping: "true"
spec:
  modelUri: hf://mistralai/Mistral-7B-Instruct-v0.3
  replicas: 1
  workerSpec:
    tensorParallelSize: 1
    resources:
      requests:
        cpu: "4"
        memory: 16Gi
        nvidia.com/gpu: "1"
      limits:
        cpu: "8"
        memory: 32Gi
        nvidia.com/gpu: "1"
    env:
      - name: HF_TOKEN
        valueFrom:
          secretKeyRef:
            name: hf-token-secret
            key: HF_TOKEN
    runtimeClassName: nvidia

All three manifests live side-by-side in kserve/generative/ and ArgoCD deploys them all automatically. This is the power of the GitOps approach—you can experiment with different deployment modes by simply committing new YAML files.

6. InferenceGraph: Multi-Model Pipelines via GitOps

KServe’s InferenceGraph CRD allows you to chain multiple models into a DAG pipeline. The reference implementation demonstrates an Ensemble + Sequence pattern:

# Source: https://github.com/AymenSegni/kserve-argo-ml-reference/blob/main/kserve/graphs/ml-pipeline-graph.yaml
apiVersion: serving.kserve.io/v1alpha1
kind: InferenceGraph
metadata:
  name: ml-pipeline
  namespace: ml-graphs
spec:
  nodes:
    root:
      routerType: Ensemble
      steps:
        - name: image-features
          serviceName: resnet50
          serviceNamespace: ml-predictive
          serviceUrl: http://resnet50-predictor.ml-predictive.svc.cluster.local
        - name: text-features
          serviceName: sentence-bert
          serviceNamespace: ml-predictive
          serviceUrl: http://sentence-bert-predictor.ml-predictive.svc.cluster.local
        - nodeName: sequence-node

    sequence-node:
      routerType: Sequence
      steps:
        - name: generator
          serviceName: mistral-batch
          serviceNamespace: ml-generative
          serviceUrl: http://mistral-batch-predictor.ml-generative.svc.cluster.local

This pipeline sends input to both ResNet-50 and Sentence-BERT in parallel (Ensemble), then feeds the combined output to Mistral-7B for generation (Sequence). Because it’s managed through ArgoCD, modifying the pipeline topology—adding a new model step, changing routing logic—is a Git commit.

7. Canary Rollouts via Git Commits

Canary deployments in KServe work by updating the same InferenceService with a new image and adding canaryTrafficPercent. With GitOps, this becomes a simple, auditable file change:

# Source: https://github.com/AymenSegni/kserve-argo-ml-reference/blob/main/kserve/canary/resnet50-canary-isvc.yaml
apiVersion: serving.kserve.io/v1beta1
kind: InferenceService
metadata:
  # Same name as original — this is an UPDATE, not a new service
  name: resnet50
  namespace: ml-predictive
spec:
  predictor:
    # 10% of traffic goes to the canary revision
    canaryTrafficPercent: 10
    containers:
      - name: kserve-container
        # Updated image (v2) — the canary
        image: ghcr.io/aymensegni/resnet50-server:v2
        ports:
          - containerPort: 8080
            protocol: TCP
        # ...same resources and probes...

The canary workflow with GitOps is clean:

1. Create a branch: git checkout -b canary/resnet50-v2
2. Copy resnet50-isvc.yaml → update the image to :v2, add canaryTrafficPercent: 10
3. Open a pull request—your team reviews the config change just like code
4. Merge → ArgoCD syncs → KServe splits traffic 90/10
5. Monitor metrics. If the canary is healthy, remove canaryTrafficPercent and push again
6. If the canary fails: git revert → ArgoCD syncs → instant rollback

No kubectl commands required. The entire canary lifecycle is a Git history.

8. KEDA Autoscaling for LLMs

For LLM workloads where Knative’s concurrency-based scaling isn’t sufficient, KEDA provides Prometheus-driven autoscaling. The reference includes a standalone ScaledObject:

# Source: https://github.com/AymenSegni/kserve-argo-ml-reference/blob/main/kserve/autoscaling/keda-mistral.yaml
apiVersion: keda.sh/v1alpha1
kind: ScaledObject
metadata:
  name: keda-mistral
  namespace: ml-generative
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: mistral-realtime-predictor-default
  minReplicaCount: 1
  maxReplicaCount: 3
  cooldownPeriod: 300
  pollingInterval: 15
  triggers:
    - type: prometheus
      metadata:
        serverAddress: "http://kube-prometheus-stack-prometheus.monitoring.svc:9090"
        metricName: vllm_active_requests
        threshold: "3"
        query: >-
          sum(vllm:num_requests_running{namespace="ml-generative",
          pod=~"mistral-realtime-predictor-default.*"})

This scales the Mistral-7B deployment based on actual vLLM active request count—a much more accurate signal than CPU utilization for GPU-bound LLM workloads. The cooldownPeriod: 300 (5 minutes) prevents premature scale-down, accounting for the high cost of LLM cold starts.

9. Monitoring via GitOps

The monitoring directory contains Prometheus ServiceMonitors and alerting rules, also managed by ArgoCD:

# monitoring/servicemonitors.yaml (excerpt)
# Source: https://github.com/AymenSegni/kserve-argo-ml-reference/blob/main/monitoring/servicemonitors.yaml
apiVersion: monitoring.coreos.com/v1
kind: ServiceMonitor
metadata:
  name: kserve-inference-metrics
  namespace: ml-monitoring
spec:
  namespaceSelector:
    matchNames:
      - ml-predictive
      - ml-generative
      - ml-graphs
  selector:
    matchExpressions:
      - key: serving.kserve.io/inferenceservice
        operator: Exists
  endpoints:
    - port: http
      path: /metrics
      interval: 15s
      honorLabels: true
    - port: metrics
      path: /metrics
      interval: 15s
      honorLabels: true

And the alerting rules fire when inference services are unhealthy:

# monitoring/alerting-rules.yaml (excerpt)
# Source: https://github.com/AymenSegni/kserve-argo-ml-reference/blob/main/monitoring/alerting-rules.yaml
apiVersion: monitoring.coreos.com/v1
kind: PrometheusRule
metadata:
  name: kserve-alerts
  namespace: ml-monitoring
spec:
  groups:
    - name: kserve.inference
      rules:
        - alert: InferenceServiceNotReady
          expr: |
            kserve_inferenceservice_status{condition="Ready",status="True"} == 0
          for: 10m
          labels:
            severity: critical
          annotations:
            summary: "InferenceService {{ $labels.name }} is not ready"

        - alert: HighInferenceErrorRate
          expr: |
            sum by (model_name, namespace) (
              rate(kserve_model_request_total{response_code!="200"}[5m])
            ) /
            sum by (model_name, namespace) (
              rate(kserve_model_request_total[5m])
            ) > 0.05
          for: 5m
          labels:
            severity: warning

    - name: kserve.vllm
      rules:
        - alert: VLLMRequestQueueGrowing
          expr: |
            sum(vllm:num_requests_waiting{namespace="ml-generative"}) > 10
          for: 5m
          labels:
            severity: warning

Because monitoring configuration is managed through ArgoCD just like the inference services, your alerting rules evolve alongside your model deployments—always in sync, always version-controlled.

IV. Production Hardening: Beyond the Lab

1. Sync Waves and Dependency Ordering

KServe has strict dependency ordering: CRDs must exist before the controller, the controller must be running before InferenceServices can be created, and InferenceServices must be deployed before InferenceGraphs can reference them.

ArgoCD’s sync-wave annotation handles this natively. You can extend the reference implementation with wave annotations on the Applications:

# Example: Adding sync-wave annotations for dependency ordering
metadata:
  name: ml-predictive
  annotations:
    argocd.argoproj.io/sync-wave: "1" # Deploy predictive models first
---
metadata:
  name: ml-generative
  annotations:
    argocd.argoproj.io/sync-wave: "1" # Deploy generative models in parallel
---
metadata:
  name: ml-graphs
  annotations:
    argocd.argoproj.io/sync-wave: "2" # Deploy graphs AFTER models exist
---
metadata:
  name: ml-monitoring
  annotations:
    argocd.argoproj.io/sync-wave: "3" # Deploy monitoring last

This ensures that InferenceGraphs are never synced before the InferenceServices they reference are available.

2. Self-Healing and Drift Detection

With selfHeal: true enabled on all Applications, ArgoCD continuously monitors for drift between Git and the cluster. This is particularly valuable for AI workloads where:

• An engineer might manually scale a deployment during a traffic spike and forget to revert
• A cluster autoscaler might mutate pod resource fields
• A KServe controller upgrade might introduce defaulting behavior that modifies your InferenceService specs

When drift is detected, ArgoCD automatically reconciles back to the Git-defined state. The orphanedResources: warn: true setting in the AppProject additionally warns you about resources in the ML namespaces that aren’t tracked by any Application—a common source of “ghost” GPU workloads consuming expensive resources.

3. ApplicationSets for Multi-Cluster AI Serving

When you need to deploy the same KServe stack across multiple clusters (e.g., us-east, eu-west, ap-southeast for low-latency global inference), ArgoCD’s ApplicationSet generator eliminates duplication:

apiVersion: argoproj.io/v1alpha1
kind: ApplicationSet
metadata:
  name: kserve-multi-cluster
  namespace: argocd
spec:
  generators:
    - list:
        elements:
          - cluster: us-east-prod
            server: https://us-east.k8s.example.com
          - cluster: eu-west-prod
            server: https://eu-west.k8s.example.com
  template:
    metadata:
      name: "ml-generative-{{cluster}}"
    spec:
      project: kserve-gitops-blueprint
      source:
        repoURL: "https://github.com/AymenSegni/kserve-gitops-blueprint.git"
        targetRevision: main
        path: kserve/generative
      destination:
        server: "{{server}}"
        namespace: ml-generative
      syncPolicy:
        automated:
          prune: true
          selfHeal: true

One YAML definition, N cluster deployments—all kept in sync automatically.

4. LocalModelCache: Solving Cold Starts via GitOps

LLM cold starts can take 10-20 minutes as models download from Hugging Face Hub. KServe’s LocalModelCache CRD pre-caches model weights on GPU nodes, and it fits perfectly into the GitOps model:

# Source: https://github.com/AymenSegni/kserve-argo-ml-reference/blob/main/kserve/generative/local-model-cache.yaml
apiVersion: serving.kserve.io/v1alpha1
kind: LocalModelCache
metadata:
  name: mistral-7b-cache
  namespace: ml-generative
spec:
  sourceModelUri: "hf://mistralai/Mistral-7B-Instruct-v0.3"
  modelSize: "15Gi"
  nodeGroup: "gpu-nodes"

The companion LocalModelNodeGroup configures which nodes participate in caching:

# Source: https://github.com/AymenSegni/kserve-argo-ml-reference/blob/main/kserve/generative/local-model-nodegroup.yaml
apiVersion: serving.kserve.io/v1alpha1
kind: LocalModelNodeGroup
metadata:
  name: gpu-nodes
  namespace: ml-generative
spec:
  nodeSelector:
    nvidia.com/gpu.present: "true"
  persistentVolumeClaim:
    accessModes:
      - ReadWriteOnce
    resources:
      requests:
        storage: 100Gi
    storageClassName: local-nvme

Because these resources are managed by ArgoCD, adding a new model to the cache is a Git commit. Removing a cached model is a file deletion. The full lifecycle is version-controlled.

Conclusion: Declarative AI Infrastructure as the Standard

KServe provides the powerful, open-source building blocks for enterprise-grade model serving—autoscaling, canary rollouts, InferenceGraphs, multi-model pipelines, and LLM-specific optimizations. ArgoCD provides the operational layer that makes these capabilities safe, repeatable, and auditable in production.

Together, they establish a pattern where:

• Every model deployment is a Git commit with a full audit trail
• Every rollback is a git revert—no panic-driven kubectl commands
• Every environment is reproducible from a single Git repository
• Every configuration drift is automatically corrected by self-healing reconciliation
• Every canary rollout is a pull request that your team reviews before merging

The kserve-argo-ml-reference repository provides a complete, production-grade starting point for this pattern. Fork it, adapt it to your models and infrastructure, and start managing your AI serving platform the way your application code is already managed—through Git.

But building, securing, and scaling a complete production AI platform around KServe and ArgoCD requires deep expertise in Kubernetes, MLOps, security, and infrastructure management. At Drizzle AI Systems (a.k.a DAIS), we specialize in exactly this—turning open-source components into battle-tested, managed AI infrastructure.

Ready to bring GitOps to your AI infrastructure?

Schedule a Free 30-Minute Strategy Session with our AI infrastructure experts. In this consultation, you’ll get:

• ✅ Architecture review of your current or planned KServe + GitOps deployment
• ✅ Repository structure recommendations tailored to your team and model portfolio
• ✅ Multi-cluster and multi-environment strategy for your specific use case
• ✅ CI/CD pipeline design for model training → registry → serving → monitoring
• ✅ Clear roadmap from proof-of-concept to production-ready GitOps infrastructure

Book Your Free Consultation →

Explore the Reference Implementation

The complete, open-source reference implementation is available on GitHub:

View the KServe GitOps Reference Repository →

Share This Guide

Found this guide helpful? Share it with your team:

Questions or feedback? Reach out to us at contact@drizzle.systems or connect with me on LinkedIn.
